10-26 SERVICING INFORMATION
FUEL TANK LOWER SIDE COVER CUSHION RUBBER/
FASTENER INSTALLATION
AIR INTAKE COVER CUSHION RUBBER INSTALLATION
NOTE:
Clean the adhesive surface before adhering the cushion rubber.
Cushion Protective tape
Cushion Align the velcro fastening to the aligned mark.
Clean an adhesive surface before adhering the cushion and
velcro fastening.
Velcro fastening
3 mm (0.12 in)
4
2
1
3
Align the cushion rubber to the
aligning mark.
