SERVICING INFORMATION 10-25
FUEL TANK INSTALLATION
Fuel tank cover Apply adhesive agent.
Velcro fastening View from bottom.
Frame cover cushion Align the fuel tank cushion with the dent mark .
Fuel tank cushion
Dent mark
“A”
“A”
“A”
“A”
“A”
“B”
“C”
“A”
“B”
“C”
