1D-Link DNS-320 User Manual
Section 1 - Product Overview
The D-Link ShareCenter™ Pulse DNS-320 2-Bay Network Storage, when used with internal SATA drives
1
, enables you to share
documents, les, and digital media such as music, photos, and video with everyone on the home or oce network. Remotely
accessing les through the Internet is also possible with the built-in FTP server, Web File server and WebDAV protocol. Whether
you are allowing access locally or over the Internet, keep data safe by only giving rights to specic users or groups. When
conguring the ShareCenter
TM
, you can create users and groups and assign them to folders with either read or read/write
permissions. This is ideal for an oce environment with employee-specic sensitive data or for the home where you can
ensure your children will only have access to age appropriate material. The ShareCenter
TM
will be available to any computer
(PC, MAC, or Linux-based) on your network, without the need to install any software on the computer.
Back up your music, photo, and video collections to the ShareCenter
TM
for safekeeping. Then, enjoy the benets of the built-in
DLNA Certied™ media server as you stream digital content to compatible media players
2
(such as the D-Link’s Boxee Box).
This feature is highly convenient as it allows you to turn o a computer that would normally be needed for the same function.
The availability of four dierent hard drive modes (Standard, JBOD, RAID 0, RAID 1) allows you to choose the conguration
best suited to your needs. Standard mode creates two separately accessible hard drives. JBOD combines both drives in linear
fashion for maximum space eciency. RAID 0 combines both drives in a ‘striped’ conguration, which provides the highest
performance when using a Gigabit Ethernet connection. RAID 1 causes the drives to mirror each other, providing maximum
protection. If one drive fails while congured as RAID 1, the unaected drive continues to function as a single drive until the
failed drive is replaced. The new drive will then be re-mirrored, allowing the ShareCenter Pulse to return to its full protection.
Introduction
2 D-Link cannot guarantee full compatibility or proper playback with all codecs. Playback capability depends on the codec support of the UPnP™ AV media player.
1 Hard Drive(s) not included.
Product Overview
