Содержание
138- Table of contents
- D link dns 323 network enclosure
- Cd rom with manual and software
- Cat 5 ethernet cable
- Power adapter 12v 3a 5v 3a
- Quick installation guide
- System requirements
- For best results the following system requirements are recommended
- Product overview
- Power cable clip
- Package contents
- Introduction
- High performance gigabit ethernet connectivity up to 23 15mbps or 184 120mbps read write
- Full or incremental backups
- Four hard drive configurations standard jbod linear raid 0 and raid
- Features
- D link easy search utility
- Users and groups can be assigned to folders with read or read write permissions
- Configurable by web browser
- Upnp av server for streaming music photos and video to compatible media player
- Built in usb print server for printing from any pc on the network
- Two hard drive bays for 3 sata hard drives of any capacit
- Built in ftp server for file access from over the interne
- The dns 323 is designed for easy installation and allows remote access to important data via the lan or wan
- Automatic e mail notifications
- Software will be able to automatically find and play music directly from the dns 323
- Simplified hard drive installation process no tools required
- Scheduled downloads from web or ftp sites
- Scandisk and defragment utilities
- Real time backups with the included backup software
- Quotas for users and groups
- Power management for conserving energy and extending hard drive life
- Power button press once to power on the dns 323 press and hold the button until it begins to blink to power down the dns 323
- Hardware overview
- Front view
- Drive leds these leds will be solid blue when drives are connected but inactive the leds will blink when the drives are being accessed formatted or synchronized they will illuminate amber if a drive has failed
- Activity led the activity led will be solid blue when there is an ethernet connection it will blink to indicate lan traffic
- Usb port usb print server port for connecting a usb printer
- Rear panel connections
- Power receptacle the 12v 3a 5v 3a power supply connects here
- Ethernet port a gigabit ethernet port that connects the dns 323 to the local network
- Drive eject lever use the provided levers to eject the hard drives the front panel must be removed before ejecting the drives
- Installation
- Hardware setup
- When first powered on during the initial boot sequence the dns 323 will wait to be assigned an ip address via dhcp if it does not receive a dhcp assigned ip address by default it will have a self assigned ip address of 192 68 2 it is recommended to use the included d link easy search utility when accessing and configuring the dns 323 for the first time if you want to change this ip address before logging in or are unable to connect to the dns 323 ip address you can use the easy search utility provided on the product cd to locate the device on your network and make any needed changes
- Easy search utility
- Configuration
- To run the easy search utility insert the dns 323 cd into your cd rom drive
- Getting started
- You will also need to select the disk format type available options are ext2 and ext3 with ext2 providing better performance and ext3 providing better support for crash recovery
- When logging into the dns 323 for the first time you will be asked to choose a drive configuration and format the drives there are four options standard jbod raid 0 and raid 1 standard configures each disk as a separate volume while jbod combines both disks into a single volume see page 46 for more details on using the raid configurations
- The login screen will appear
- When prompted to configure the hard drive settings
- When formatting of the drive completes the dns 323 will restart a restart countdown screen will appear and when the restart is complete the login screen will appear
- After logging in you will be redirected to the dns 323 web ui
- Web ui
- Wizard
- The dns 323 has a setup wizard that allows you to quickly configure some of the basic device settings
- The local area network settings for the dns 323 are configured on the lan page
- The device settings page allows you to assign a workgroup name and description to the dns 323
- Device settings
- The dns 323 supports up to 64 unique users the users can be specified by group or created individually the users are created to allow access to specific folders on the dns 323 via ftp or the local network
- Advanced
- The dns 323 supports up to 10 unique groups users can be assigned to groups for ease of management and to aid in organization when setting up access rules and quotas
- Groups
- The dns 323 supports storage quotas for both groups and individual users assigning a quota to a group or user will limit the amount of storage they are allocated by default users and groups do not have a quota
- Quotas
- Configuring quotas
- By default all users and groups are displayed on the quota settings page users and groups are automatically listed on this page and cannot be deleted the default quota setting is unlimited
- To add a quota
- The network access settings allow you to assign users and groups to specific folders or volumes by default all users are allowed read write access to all volumes before specific user or group rules can be created the default rules must be deleted
- Network access
- The dns 323 is equipped with a built in ftp server the server is easy to configure and allows users access to important data whether they are on the local network or at a remote location the ftp server can be configured to allow user access to specific directories and will allow up to 10 users to access the dns 323 at a time
- Ftp server
- Ftp server settings
- If you use an ftp port other than 21 then users accessing the ftp server using an ftp client will have to specify the non standard port and users who are using a browser will have to specify the port in the url e g ftp ftp dns323 com 3000
- If you are using a d link router such as the wbr 2310 used in the example below your port forwarding rule should be similar to the following
- If you are behind a router you will need to forward the ftp port from the router to the dns 323 additional filtering and firewall settings may need to be modified on your router to allow ftp access to the dns 323 from the internet once the port has been forwarded on the router users from the internet will access the ftp server through the wan ip address of the router
- Upnp av server
- The dns 323 features a upnp av server this server provides the ability to stream photos music and videos to upnp av compatible network media players if the server is enabled the dns 323 will be automatically detected by upnp av compatible media players on your local network
- The dns 323 features an itunes server this server provides the ability to share music and videos to computers on the local network running itunes if the server is enabled the dns 323 will be automatically detected in the itunes program and the music and videos contained in the specified directory will be available to stream over the network
- Itunes server
- After enabling the itunes server on the dns 323 launch itunes when itunes detects the dns 323 select it and you will be prompted to enter the itunes server password
- The dns 323 can also be used as a dhcp server as a dhcp server it can be used to serve ip addresses to devices on your local network however this feature should not be enabled if you already have a dhcp server such as a router on your local network
- Dhcp server
- The admin menu allows you to set a password for the admin account it is recommended to set an admin account password when first configuring the dns 323
- Click save settings to save the new password
- The dns 323 time menu contains several different options for setting the device s internal clock it is important that accurate time is set so that scheduled backups and downloads will be accurate
- The dns 323 system menu provides options for system restarts saving and loading configuration settings and setting idle times
- System
- The dns 323 firmware menu makes it simple to check for new firmware releases and upload them to the device
- Firmware
- With the dns 323 e mail alerts you can configure e mails to be sent alerting you to certain operational conditions and drive status conditions these alerts can prove helpful with the management and safeguarding of important data
- E mail alerts
- E mail alert settings
- E mail alert types
- The dns 323 has scan disk and defgrament utilities to help the device performance
- Disk utilities
- The dns 323 power management feature allows you to configure the drives to shut down while power remains constant to the device the drives will power up again when data is accessed
- Power management
- Raid 0
- What is raid
- Raid short for redundant array of independent disks is a combination of two or more disks with the aim of providing fault tolerance and improving performance there are several different levels of raid with each providing a different method of sharing or distributing data amongst the drives the dns 323 supports raid levels 0 and 1
- Raid 1
- Status
- Device info
- The dns 323 support page provides a menu of support topics explaining the features of the device
- Support
- You can use the d link easy search utility to map drives to your computer insert the dns 323 cd into your cd rom drive
- The easy search utility will load and detect any dns 323 devices that are on the local network
- Mapping a drive
- Once connected your mapped drive s will appear in my computer
- If the dns 323 you are working with does not show up in the device list click refresh
- The dns 323 download scheduling feature allows you to set up scheduled folder or file downloads and backup sessions
- Download scheduling
- Begin by accessing the configuration of the dns 323
- The dns 323 download scheduling configuration will appear
- The dns 323 login screen will appear
- Scheduling
- Scheduling settings
- Usb print server
- To add a printer
- The dns 323 features a built in usb print server giving users the ability to share a printer on their local network connect a usb printer to the usb port on the back of the dns 323 it is important to ensure that any of the printer manufacturer s drivers are already installed on any computer you want to print from
- The windows add printer wizard will launch
- The following printer driver messages will appear
- Contacting technical support
- Warranty
- Limited warranty
- Non applicability of warranty
- Limited software warranty
- What is not covered
- Disclaimer of other warranties
- Copyright statement
- Trademarks
- Limitation of liability
- Governing law
- Registration
- Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights
