53D-Link DNS-323 User Manual

Section 3 - Conﬁguration

Download Scheduling

The DNS-323 Download Scheduling feature allows you to set up scheduled folder or ﬁle downloads and backup

sessions.

Begin by accessing the conﬁguration of the DNS-323:

Click Easy Search Utility.

Highlight an available DNS-323

and click Conﬁguration to access

the web-based utility.
