61D-Link DNS-323 User Manual

Section 3 - Conﬁguration

The following printer driver messages will appear:

Click Next to continue.

Click OK to continue and select

a printer driver.

Select the appropriate printer driver from the

list and click OK to complete the wizard. If the

driver is not in the list, select Have Disk.
