30D-Link DNS-323 User Manual
Section 3 - Configuration
FTP Server
FTP Server
Settings
FTP Server
Status
The DNS-323 is equipped with a built in FTP Server. The server is easy to configure and allows users access to
important data whether they are on the local network or at a remote location. The FTP server can be configured to
allow user access to specific directories, and will allow up to 10 users to access the DNS-323 at a time.
T h i s s e c t i o n c o n t a i n s t h e
configuration settings for the
DNS-323 FTP Server. Click Apply
to save the settings.
The current settings and status
of the DNS-323 FTP Server are
displayed here.
