D-Link DNS-323 [7/70] Rear panel connections
![D-Link DNS-323 [7/70] Rear panel connections](/views2/1045661/page7/bg7.png)
7D-Link DNS-323 User Manual
Section 1 - Product Overview
Power Receptacle:
The 12V 3A / 5V 3A power supply connects here.
Ethernet Port:
A Gigabit Ethernet port that connects the DNS-323 to the local network.
USB Port:
USB Print Server port for connecting a USB printer.
Drive Eject Lever:
Use the provided levers to eject the hard drives. The front panel must be removed before ejecting the drives.
Rear Panel (Connections)
Ethernet Port
Power Recpetacle
USB Port
Drive Eject Lever
Drive Eject Lever
