D-Link DNS-323 [54/70] The dns 323 download scheduling configuration will appear

54D-Link DNS-323 User Manual

Section 3 - Conﬁguration

Type admin for the username

and leave the password ﬁeld

blank.

Click Download Schedule.

The DNS-323 login screen will appear:

The DNS-323 Download Scheduling conﬁguration will appear.
