35D-Link DNS-323 User Manual
Section 3 - Configuration
After enabling the iTunes server on the DNS-323, launch iTunes. When iTunes detects the DNS-323, select it and you
will be prompted to enter the iTunes server password.
Select the DNS-323. When
prompted, enter in the iTunes
server password. Click OK.
Media stored on the DNS-323
will then be available for use in
iTunes.
