D-Link DNS-323 [14/70] When prompted to configure the hard drive settings

14D-Link DNS-323 User Manual

Section 3 - Conﬁguration

Select the type of hard drive conﬁguration, Standard,

JBOD, RAID 0 or RAID 1.

A warning message appears informing you that your

drives will be formatted and all data erased. Click

OK to continue.

When prompted to conﬁgure the Hard Drive Settings:
