15D-Link DNS-323 User Manual
Section 3 - Configuration
Select the disk format type, EXT2 or EXT3.
When formatting of the drive completes, the DNS-323 will restart. A restart countdown screen will appear, and when
the restart is complete, the login screen will appear:
Type admin for the username and
leave the password field blank.
Click Config
Note: After logging in to the DNS-323 for the first time it is recommended to add a password to the admin account.
(See p. 37 for details.)
