- 11 -
Hardware Installation
Storage Interface Chipset:
- 2 x M.2 Socket 3 connectors
- 3 x SATA Express connectors
- 6 x SATA 6Gb/s connectors (SATA3 0~5)
- Support for RAID 0, RAID 1, RAID 5, and RAID 10
* Referto"1-13InternalConnectors,"forthesupportedcongurationswiththeM.2,
SATA Express, and SATA connectors.
2 x ASMedia
®
ASM1061 chips:
- 4 x SATA 6Gb/s connectors (SATA3 6~7, GSATA3 8~9), supporting AHCI
mode only
USB Chipset:
- 4 x USB 3.0/2.0 ports on the back panel
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
the internal USB headers)
Chipset+2 Renesas
®
USB 3.0 Hubs:
- 7 x USB 3.0/2.0 ports (3 ports on the back panel, 4 ports available through
the internal USB headers)
Chipset+Intel
®
Thunderbolt
™
3 Controller:
- 1 x USB Type-C
™
portonthebackpanel,withUSB3.1support
- 1 x USB 3.1 Type-A port (red) on the back panel
Internal
Connectors
1x24-pinATXmainpowerconnector
1x8-pinATX12Vpowerconnector
1xPCIepowerconnector
1xI/OshieldaudioLEDpowerconnector
2 x M.2 Socket 3 connectors
3 x SATA Express connectors
10 x SATA 6Gb/s connectors
1 x CPU fan header
1xwatercoolingfanheader(CPU_OPT)
5 x system fan headers
1 x front panel header
1 x front panel audio header
2 x USB 3.0/2.0 headers
2 x USB 2.0/1.1 headers
1 x Trusted Platform Module (TPM) header
1 x Clear CMOS jumper
1xpowerbutton
1 x reset button
1 x Clear CMOS button
1 x ECO button
1 x OC button
2xaudiogaincontrolswitches
2xBIOSswitches
Voltage Measurement Points
