- 12 -
Hardware Installation
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1 x HDMI port
1 x USB Type-C
™
port,withUSB3.1support
1 x USB 3.1 Type-A port (red)
7 x USB 3.0/2.0 ports
2 x USB 2.0/1.1 ports
2 x RJ-45 ports
1 x optical S/PDIF Out connector
5xaudiojacks(Center/SubwooferSpeakerOut,RearSpeakerOut,LineIn/Mic
In, Line Out, Headphone)
2 x MMCX antenna connectors (2T2R)
I/O Controller iTE
®
I/O Controller Chip
Hardware
Monitor
System voltage detection
CPU/System/Chipset temperature detection
CPU/CPU OPT/System fan speed detection
CPU/System/Chipsetoverheatingwarning
CPU/CPUOPT/Systemfanfailwarning
CPU/CPU OPT/System fan speed control
* Whetherthefanspeedcontrolfunctionissupportedwilldependonthecooleryou
install.
BIOS 2x128Mbitash
Use of licensed AMI UEFI BIOS
Support for DualBIOS
™
Support for Q-Flash Plus
* TheUSBashdriveusedmustbeaUSB2.0ashdrive.
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported
functionsofeachapplicationmayalsovarydependingonmotherboardspecications.
- 3D OSD
- @BIOS
- Ambient LED
- AutoGreen
- Cloud Station
- EasyTune
- Easy RAID
- Fast Boot
- Smart TimeLock
- Smart Keyboard
- Smart Backup
- SystemInformationViewer
- USB Blocker
Support for Q-Flash
SupportforSmartSwitch
Support for Xpress Install
