Chapter 9 VLAN
XGS-4526/4528F/4728F User’s Guide
130
The following table describes the labels in this screen.
Table 21 Advanced Application > VLAN > VLAN Port Setting > Protocol Based
VLAN Setup
LABEL DESCRIPTION
Active Check this box to activate this protocol based VLAN.
Port Type a port number to be included in this protocol based VLAN.
This port must belong to a static VLAN in order to participate in a protocol
based VLAN. See Chapter 9 on page 117 for more details on setting up
VLANs.
Name Enter up to 32 alphanumeric characters to identify this protocol based
VLAN.
Ethernet-
type
Use the drop down list box to select a predefined protocol to be included in
this protocol based VLAN or select Others and type the protocol number in
hexadecimal notation. For example, the IP protocol in hexadecimal
notation is 0800, and Novell IPX protocol is 8137.
Note: Protocols in the hexadecimal number range of 0x0000 to 0x05ff
are not allowed to be used for protocol based VLANs.
VID Enter the ID of a VLAN to which the port belongs. This must be an existing
VLAN which you defined in the Advanced Applications > VLAN screens.
Priority Select the priority level that the Switch will assign to frames belonging to
this VLAN.
Add Click Add to save your changes to the Switch’s run-time memory. The
Switch loses these changes if it is turned off or loses power, so use the
Save link on the top navigation panel to save your changes to the non-
volatile memory when you are done configuring.
Cancel Click Cancel to begin configuring this screen afresh.
Index This is the index number identifying this protocol based VLAN. Click on any
of these numbers to edit an existing protocol based VLAN.
Active This field shows whether the protocol based VLAN is active or not.
Port This field shows which port belongs to this protocol based VLAN.
Name This field shows the name the protocol based VLAN.
Ethernet-
type
This field shows which Ethernet protocol is part of this protocol based
VLAN.
VID This field shows the VLAN ID of the port.
Priority This field shows the priority which is assigned to frames belonging to this
protocol based VLAN.
Delete Click this to delete the protocol based VLANs which you marked for
deletion.
Cancel Click Cancel to begin configuring this screen afresh.
