Chapter 37 OSPF
XGS-4526/4528F/4728F User’s Guide
339
37.4.1 View OSPF Area Information Table
The bottom of the OSPF Configuration screen displays a summary table of all
the OSPF areas you have configured.
Figure 164 IP Application > OSPF Configuration: Summary Table
The following table describes the related labels in this screen.
37.5 Configuring OSPF Redistribution
Use this screen to configure route redistribution and summary addresses. Route
redistribution is used when other routers which use RIP routing protocol and/or
static routes need to exchange routing information with the Switch using OSPF
routing protocol. A summary address is used to cover more than one routing
entries in order to reduce the routing table size.
Add Click Add to save your changes to the Switch’s run-time memory. The
Switch loses these changes if it is turned off or loses power, so use the
Save link on the top navigation panel to save your changes to the non-
volatile memory when you are done configuring.
Cancel Click Cancel to begin configuring this screen afresh.
Clear Click Clear to set the above fields back to the factory defaults.
Table 118 IP Application > OSPF Configuration: Area Setup (continued)
LABEL DESCRIPTION
Table 119 IP Application > OSPF Configuration: Summary Table
LABEL DESCRIPTION
Index This field displays the index number of an area.
Name This field displays the descriptive name of an area.
Area ID This field displays the area ID (that uses the format of an IP address in
dotted decimal notation) that uniquely identifies an area.
An area ID of 0.0.0.0 indicates the backbone.
Authenticati
on
This field displays the authentication method used (None, Simple or
MD5).
Stub
Network
This field displays whether an area is a stub network (Yes) or not (No).
Delete Click Delete to remove the selected entry from the summary table.
Cancel Click Cancel to clear the Delete check boxes.
