Chapter 26 IP Source Guard
XGS-4526/4528F/4728F User’s Guide
265
new static binding replaces the original one. To open this screen, click Advanced
Application > IP Source Guard > Static Binding.
Figure 118 IP Source Guard Static Binding
The following table describes the labels in this screen.
Table 78 IP Source Guard Static Binding
LABEL DESCRIPTION
MAC Address Enter the source MAC address in the binding.
IP Address Enter the IP address assigned to the MAC address in the binding.
VLAN Enter the source VLAN ID in the binding.
Port Specify the port(s) in the binding. If this binding has one port,
select the first radio button and enter the port number in the field
to the right. If this binding applies to all ports, select Any.
Add Click this to create the specified static binding or to update an
existing one.
Cancel Click this to reset the values above based on the last selected static
binding or, if not applicable, to clear the fields above.
Clear Click this to clear the fields above.
Index This field displays a sequential number for each binding.
MAC Address This field displays the source MAC address in the binding.
IP Address This field displays the IP address assigned to the MAC address in
the binding.
Lease This field displays how long the binding is valid.
Type This field displays how the Switch learned the binding.
static: This binding was learned from information provided
manually by an administrator.
VLAN This field displays the source VLAN ID in the binding.
Port This field displays the port number in the binding. If this field is
blank, the binding applies to all ports.
