Chapter 24 Multicast
XGS-4526/4528F/4728F User’s Guide
238
802.1p Priority Select a priority level (0-7) with which the Switch replaces the priority in
outgoing IGMP control packets (belonging to this multicast VLAN).
Mode Specify the MVR mode on the Switch. Choices are Dynamic and
Compatible.
Select Dynamic to send IGMP reports to all MVR source ports in the
multicast VLAN.
Select Compatible to set the Switch not to send IGMP reports.
Port This field displays the port number on the Switch.
* Settings in this row apply to all ports.
Use this row only if you want to make some settings the same for all
ports. Use this row first to set the common settings and then make
adjustments on a port-by-port basis.
Note: Changes in this row are copied to all the ports as soon as you
make them.
Source Port Select this option to set this port as the MVR source port that sends and
receives multicast traffic. All source ports must belong to a single
multicast VLAN.
Receiver Port Select this option to set this port as a receiver port that only receives
multicast traffic.
None Select this option to set the port not to participate in MVR. No MVR
multicast traffic is sent or received on this port.
Tagging Select this checkbox if you want the port to tag the VLAN ID in all
outgoing frames transmitted.
Add Click Add to save your changes to the Switch’s run-time memory. The
Switch loses these changes if it is turned off or loses power, so use the
Save link on the top navigation panel to save your changes to the non-
volatile memory when you are done configuring.
Cancel Click Cancel to begin configuring this screen afresh.
VLAN This field displays the multicast VLAN ID.
Active This field displays whether the multicast group is enabled or not.
Name This field displays the descriptive name for this setting.
Mode This field displays the MVR mode.
Source Port This field displays the source port number(s).
Receiver Port This field displays the receiver port number(s).
802.1p This field displays the priority level.
Delete To delete a multicast VLAN(s), select the rule(s) that you want to
remove in the Delete column, then click the Delete button.
Cancel Click Cancel to clear the Delete check boxes.
Table 66 Advanced Application > Multicast > Multicast Setting > MVR (continued)
LABEL DESCRIPTION
