Chapter 52 ARP Table
XGS-4526/4528F/4728F User’s Guide
452
52.2 The ARP Table Screen
Click Management > ARP Table in the navigation panel to open the following
screen. Use the ARP table to view IP-to-MAC address mapping(s) and remove
specific dynamic ARP entries.
Figure 243 Management > ARP Table
The following table describes the labels in this screen.
Table 168 Management > ARP Table
LABEL DESCRIPTION
Condition Specify how you want the Switch to remove ARP entries when you click
Flush.
Select All to remove all of the dynamic entries from the ARP table.
Select IP Address and enter an IP address to remove the dynamic entries
learned with the specified IP address.
Select Port and enter a port number to remove the dynamic entries
learned on the specified port.
Flush Click Flush to remove the ARP entries according to the condition you
specified.
Cancel Click Cancel to return the fields to the factory defaults.
Index This is the ARP table entry number.
IP Address This is the learned IP address of a device connected to a Switch port with
the corresponding MAC address below.
MAC
Address
This is the MAC address of the device with the corresponding IP address
above.
VID This field displays the VLAN to which the device belongs.
Port This field displays the port to which the device connects. CPU means this
learned IP address is the Switch’s management IP address.
Type This shows whether the MAC address is dynamic (learned by the Switch) or
static (manually entered in the Static MAC Forwarding screen).
