Chapter 30 sFlow
XGS-4526/4528F/4728F User’s Guide
298
The following table describes the labels in this screen.
Table 94 Advanced Application > sFlow > Collector
LABEL DESCRIPTION
Collector
Address
Enter the IP address of the sFlow collector.
UDP Port Enter a UDP port number the Switch uses to send sFlow datagram to the
collector. If you change the port here, make sure you change it on the
collector, too. The default port is 6343.
Add Click Add to save your changes to the Switch’s run-time memory. The
Switch loses these changes if it is turned off or loses power, so use the
Save link on the top navigation panel to save your changes to the non-
volatile memory when you are done configuring.
Cancel Click Cancel to reset the fields to your previous configuration.
Clear Click Clear to clear the fields to the factory defaults.
Index This field displays the index number of this entry.
Collector
Address
This field displays IP address of the sFlow collector.
UDP Port This field displays port number the Switch uses to send sFlow datagram to
the collector.
Delete Check the rule(s) that you want to remove in the Delete column and then
click the Delete button.
Cancel Click Cancel to begin configuring this screen afresh.
