XGS-4526/4528F/4728F User’s Guide
173
CHAPTER 15
Broadcast Storm Control
This chapter introduces and shows you how to configure the broadcast storm
control feature.
15.1 Broadcast Storm Control Setup
Broadcast storm control limits the number of broadcast, multicast and destination
lookup failure (DLF) packets the Switch receives per second on the ports. When
the maximum number of allowable broadcast, multicast and/or DLF packets is
reached per second, the subsequent packets are discarded. Enable this feature to
reduce broadcast, multicast and/or DLF packets in your network. You can specify
limits for each packet type on each port.
Click Advanced Application > Broadcast Storm Control in the navigation
panel to display the screen as shown next.
Figure 71 Advanced Application > Broadcast Storm Control
