Chapter 49 Cluster Management
XGS-4526/4528F/4728F User’s Guide
437
The following table describes the labels in this screen.
49.2.1 Cluster Member Switch Management
Go to the Clustering Management Status screen of the cluster manager switch
and then select an Index hyperlink from the list of members to go to that cluster
member switch's web configurator home page. This cluster member web
Table 163 Management > Cluster Management
LABEL DESCRIPTION
Status This field displays the role of this Switch within the cluster.
Manager
Member (you see this if you access this screen in the cluster member
switch directly and not via the cluster manager)
None (neither a manager nor a member of a cluster)
Manager This field displays the cluster manager switch’s hardware MAC address.
The Number
of Member
This field displays the number of switches that make up this cluster. The
following fields describe the cluster member switches.
Index You can manage cluster member switches via the cluster manager switch.
Each number in the Index column is a hyperlink leading to the cluster
member switch’s web configurator (see Figure 236 on page 438).
MacAddr This is the cluster member switch’s hardware MAC address.
Name This is the cluster member switch’s System Name.
Model This field displays the model name.
Status This field displays:
Online (the cluster member switch is accessible)
Error (for example, the cluster member switch password was changed or
the switch was set as the manager and so left the member list, etc.)
Offline (the switch is disconnected - Offline shows approximately 1.5
minutes after the link between cluster member and manager goes down)
