Chapter 49 Cluster Management
XGS-4526/4528F/4728F User’s Guide
441
Apply Click Apply to save your changes to the Switch’s run-time memory.
The Switch loses these changes if it is turned off or loses power, so
use the Save link on the top navigation panel to save your changes to
the non-volatile memory when you are done configuring.
Cancel Click Cancel to begin configuring this screen afresh.
Clustering
Candidate
The following fields relate to the switches that are potential cluster
members.
List A list of suitable candidates found by auto-discovery is shown here.
The switches must be directly connected. Directly connected switches
that are set to be cluster managers will not be visible in the
Clustering Candidate list. Switches that are not in the same
management VLAN group will not be visible in the Clustering
Candidate list.
Password Each cluster member’s password is its web configurator password.
Select a member in the Clustering Candidate list and then enter its
web configurator password. If that switch administrator changes the
web configurator password afterwards, then it cannot be managed
from the Cluster Manager. Its Status is displayed as Error in the
Cluster Management Status screen and a warning icon ( )
appears in the member summary list below.
If multiple devices have the same password then hold [SHIFT] and
click those switches to select them. Then enter their common web
configurator password.
Add Click Add to save your changes to the Switch’s run-time memory. The
Switch loses these changes if it is turned off or loses power, so use the
Save link on the top navigation panel to save your changes to the
non-volatile memory when you are done configuring.
Cancel Click Cancel to begin configuring this screen afresh.
Refresh Click Refresh to perform auto-discovery again to list potential cluster
members.
The next summary table shows the information for the clustering members configured.
Index This is the index number of a cluster member switch.
MacAddr This is the cluster member switch’s hardware MAC address.
Name This is the cluster member switch’s System Name.
Model This is the cluster member switch’s model name.
Remove Select this checkbox and then click the Remove button to remove a
cluster member switch from the cluster.
Cancel Click Cancel to begin configuring this screen afresh.
Table 165 Management > Clustering Management > Configuration (continued)
LABEL DESCRIPTION
