DG834G Reference Manual
Virtual Private Networking 8-23
v3.0, September 2005
3. Fill in the IP Address or FQDN for the target VPN endpoint WAN connection and click Next.
Figure 8-22: Remote IP
4. Identify the IP addresses at the target endpoint which can use this tunnel, and click Next.
Figure 8-23: Secure Connection Remote Accessibility
The Summary screen below displays.
Enter the WAN IP address of the remote
VPN gateway: (e.g., 22.23.24.25)
Enter the LAN IP settings of the remote
VPN gateway:
• IP Address (e.g., 192.168.3.1)
• Subnet Mask (e.g., 255.255.255.0)
