Startup
309301K 23
Startup
Follow this procedure to start the ProDispense system for the first time (initial startup) or after the system has been
shut down.
1. Turn on the power. The ProDispense system startup screen will display while the system is starting, then the Run
screen (page 30) or System Setup screen (page 26) will appear, depending on the mode of operation the system
is in. For an explanation of operation modes, see page 11.
2. If this is the initial startup, change to Setup Mode (page 25) and complete the setup procedures.
3. Change to the Dispense Mode Run screen if you are not there already (page 29).
4. Make sure the dispense lines run into the proper reservoir.
5. Load the fluids (page 34).
FloSync
Software revision
ProDispense: Rev. X.XX
Startup screen
