Dispense Mode
32 309301K
Press the left or right arrow key to select Totals
.
The Fluid Totals
screen shows how much of each of the fluids
has been dispensed overall. Two totals are shown. Grand totals are tracked from the time the system is first started
up and they are not resettable. Resettable totals show the total amount of each fluid dispensed since the last reset.
Fluid Totals Screen
Totals
Press Print key to print Fluid Totals Report.
Press Clear and Enter keys simultaneously to reset all
resettable totals.
FLUID TOTALS
Fluid# Resettable Grand
1 00005.1 ltr 00312.1 ltr
2 00005.2 ltr 00582.8 ltr
3 00004.8 ltr 00468.2 ltr
Last Reset
Date:23/04/01
Time: 07:35
Press ENTER and CLEAR to reset totals
Run
Totals Alarms
Clear Print
+
All resettable totals are reset when Clear and
Enter are pressed. Fluid totals cannot be
reset individually.
!
