Graco ProDispense [27/74] Fluid setup screen

Setup Mode

309301K 27

Use fluid setup to designate the parameters for each fluid you will dispense.

Fluid Setup Screen

Fluids

NOTE: Fluid parameters must be set before the fluid can be used in a recipe.

To set up the fluids:

You can have 1-3 fluid panels connected to the ProDis-

pense controller. Setup the fluids for each of your fluid

panels as follows:

1. Type the number for the desired units of measure

(1-5).

2. Type the dispense tolerance percentage (1-99).

3. Type the timeout value in minutes (1-99).

If a dispense does not complete by the end of the

entered value, a Dispense Timeout alarm occurs.

See page 33.

4. Type the fluid meter’s K-factor (cc/pulse).

NOTE: The K-factors in the table are a starting point.

You can calibrate the meter as instructed on page 28.

5. Repeat steps 1-4 for each additional fluid panel.

6. Press the right arrow key to go to the Recipe

Setup screen.

FLUID SETUP

Fluid 1 Fluid 2 Fluid 3

Units of Measure

1=cc 2=oz 3=Qt

4=Ltr 5=Gal

Tolerance %

Timeout Value (min)

K-factor (cc/pulse)

System Fluids Recipes Meters

Fluid Panel

part no.

Meter Type K-factor

(cc/pulse)

244599 oil/lubricant 4.73

244600 water/antifreeze 25

244601 grease/coating 0.119

246837 grease/coating .061

246838 grease/coating n/a

246839 grease/coating 0.286
