ProDispense System Components
4 309301K
ProDispense System Components
Follow the instructions in this manual (309301) and refer
to the component manuals for additional warning, oper-
ation, service, and parts information. See the table
below for:
• maximum working pressure of the fluid panels
• component part numbers and manual numbers
• parts list page numbers
Fluid Panels Part No. 244599
Oil/Lubricant
* 244600
Water/Antifreeze
244601
Grease/Paint
Maximum Working Pressure 1500 psi (10 MPa, 103 bar) 250 psi (1.7 MPa, 17 bar) 3000 psi (21 MPa, 207 bar)
Fluid Meter Part No. 238618 513891 239716
Manual No. 308245 — 308778
Dispense Valve Part No. — — 205612
Manual No. — — 306715
Parts List Page No. 64 65 66
Fluid Panels Part No. 246837
Grease/Paint
246838
Meterless
246839
Sealants
Maximum Working Pressure 3000 psi (21 MPa, 207 bar) 3000 psi (21 MPa, 207 bar) 3000 psi (21 MPa, 207 bar)
Fluid Meter Part No. 244292 — 246190
Manual No. 308778 — 309834
Dispense Valve Part No. 205612 205612 205612
Manual No. 306715 306715 306715
Parts List Page No. 69 70 71
ProDispense Controller Part No. 244561
Parts List Page No. 62
Remote Operator Station Part No. 116669
* The fluid meter used on Part No. 244600 is not ETL listed.
