Graco ProDispense [60/74] Accessories wiring chart
![Graco ProDispense [60/74] Accessories wiring chart](/views2/1193399/page60/bg3c.png)
Service
60 309301K
Accessories Wiring Chart
Harness
Connection
(Connector-Pin)
Color Function
197458
(5 ft., 1.52 m)
198669
(50 ft. 15.24 m)
Printer Cable
2 1 shield
33clear
15black
4
jumper
6
Field Wiring Chart - Output
Harness
Connection
(Connector-Pin)
Color Function
J5-1 ground
J5-2 General Alarm (24 VDC)
J5-3 ground
J5-4 Fluid 1 Alarm (24 VDC)
J5-5 ground
J5-6 Fluid 2 Alarm (24 VDC)
J5-7 ground
J5-8 Fluid 3 Alarm (24 VDC)
J3-8 Modbus B
J3-9 Modbus A
J2-6 ground
