Setup Mode
26 309301K
Use system setup to enter the date, time, language to display, dispense mode, means of recipe selection and station
number.
System Setup Screen
To setup the system:
1. Type the current date: day (1-31) ,
month (1-12) , year (2000-2099) .
2. Type the current time: hour (0-23) ,
minute (0-59) .
NOTE: The ProDispense clock is a 24 hour clock. The
date and time are used for date/time stamps on alarms
and reports.
3. Type the desired language number (1-5).
NOTE: Power must be cycled before the language
change will take affect.
4. Type the number for the desired dispense mode
(1-2).
Fluid Station: use this mode to select individual
fluid stations when dispensing.
Recipe: use this mode to select a recipe when dis-
pensing. Dispensing by recipe will signal all fluid sta-
tions included in the recipe to dispense
simultaneously.
5. Type the number for the desired recipe selection
(1-2).
User Interface: use to select recipes from the
EasyKey pad.
Network: use to select recipes from a networked
source.
6. Type the station number (1-99).
NOTE: This number is used for network communications
to identify the station. Each station must have a unique
number.
7. Press the right arrow key to go to the Fluid Setup
screen.
System
SYSTEM SETUP
Day/Month/Year: Dispense Mode:
1=Fluid Station
Hour:Minute 2=Recipe
Language:
Recipe Selection:
1=User Interface
1=English 2=Spanish 2=Network
3=German 4=French
5=Japanese Station Number:
System Fluids Recipes Meters
