5
English
STANDARD ACCESSORIES
(1) Side handle ............................................................... 1
(2) Case ........................................................................... 1
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES
(sold separately)
1. Variety of sockets
Although the Hitachi Impact Wrench is delivered
with only one standard socket, ample sockets are
available to cover impact tightening of various sizes
and types of bolts.
SPECIFICATIONS
Voltage (by areas)* (110V, 115V, 120V, 127V, 220V, 230V, 240V)
Power input* 420 W
No load speed (Low/High) 0 - 1800 / 0 - 2300 min
-1
Capacities (size of bolts)
M8-M14 (High tension bolt)
M10-M18 (Ordinary bolt)
Tightening torque**
Low: Maximum 18.8 kg-m
High: Maximum 25.5 kg-m
Angle drive 12.7 mm
Weight (without cord) 2.2 kg
*Be sure to check the nameplate on product as it is subject to change by areas.
**Tightening the bolt without extension cord at rated voltage.
S
D
B
E
L
Table 1 B = 12.7 mm
Socket
Ordinary Socket Long Socket
Designation
Dimension (mm) Dimension (mm)
Hex. Socket 12
13
14
17
19
21
22
23
24
26
27
S
14
17
19
21
22
23
24
26
27
D
25
28
28
32
35
36
38
38
42
E
24
15
17
19
24
25
25
25
24
L
40
32
34
36
40
40
40
40
50
S
12
13
14
17
19
21
22
23
24
26
27
D
20
21.5
22
25
28
31
32.5
33
34
38
40
E
34
34
34
34
34
34
34
34
34
57
57
L
52
52
52
52
52
52
52
52
52
75
75
PRECAUTIONS ON USING IMPACT WRENCH
1. When using the tool at a height, make sure that
there is nobody below.
2. Use earplugs if using for a long time use.
3. Switch the reversing switch only after the motor
has stoped when it is necessary to change the
direction of the rotation.
4. Use a step up transformer when a long extension
cable is used.
5. Confirm the tightening torque by a torque wrench
before use in order to ascertain the correct tightening
torque to be used.
6. Assemble the socket securely to the impact wrench
with the socket pin and ring.
7. Confirm whether the socket has any cracks in it.
8. Always hold the body and side handles of the impact
wrench firmly. Otherwise the counterforce produced
may result in inaccurate and even dangerous operation.
01Eng_WR14VB_EE 12/4/08, 11:525
