12
the handle. A contact with the power mains network may transfer
voltage onto metal parts of the power tool, which may result in
electric shock.
• The power cord must be kept away from the rotating working
tools. When the control over the tool is lost, the power cord may
be cut or caught, and your hand or the entire arm may get into the
rotating working tool.
• Do not put the power tool aside, before the working tool
comes to complete stop. The rotating working tool may come in
contact with a surface, which it is put aside onto, and you may lose
control over the tool.
• Do not carry the power tool, which is in motion. An accidental
contact with the rotating working tool may caught in your clothes
and drill into an operator’s body.
• Clean ventilation slots of the power tool on a regular basis. The
motor blower sucks dust into the casing, while large accumulation of
metal dust may cause electric hazard.
• Do not use the power tool near ammable materials. Sparks
may cause ignition.
• Do not use tools, which require liquid cooling agents. The use
of water or other cooling agents may cause electric shocks.
Recoil and proper safety guidelines
• Recoil is a sudden reaction of the power tool to seizure or
blocking of a rotating working tool, such a grinding wheel, cut-
o wheel or a wire brush, etc.
The seizure and blocking may suddenly stop a rotating working
tool. The power tool without control will be jerked in the
opposite direction to the working tool.
When the grinding wheel stops or catches in the workpiece, an
edge od the grinding wheel immersed in the workpiece may
lock and cause recoil or rejection. The movement of the grinding
wheel (towards or away from the operator) depends on the
movement of the grinding wheel in a place, where it is locked.
The grinding wheels may also break.
Recoil is a consequence of incorrect operation of the power tool.
This can be avoided by observing the following precautions.
• The power tool must be held rmly, while your body and
hands should be positioned to alleviate recoil. If the additional
handle is included as standard equipment, it should be used
at all times to provide the highest control over recoil forces or
rejecting moment during start-up. An operator can take control
of recoil and jerking by taking proper precautions.
• Never hold your hands in the vicinity of rotating working
tools. A working tool may injure your hand as a result of recoil.
• Always keep your hands away from rotating working tools. As
a result of kick back, working tool may cause hand injury.
• Always stay away from the reach zone, in which the power tool
moves during recoil. As a result of recoil, the power tool moves in
the opposite direction to the movement of the grinding wheel, where
it locks.
• Corners, sharp edges, etc. should be worked with special
attention. Recoil or locking of the working tools should be
prevented. A rotating working tool is more prone to seizure, when
working angles, corners, sharp edges or when it is rebound. This may
result in loss of control or recoil.
• Do not use discs for wood or toothed discs. Working tools of this
type often cause recoil or loss of control over the working tool.
Special safety guidelines for grinding and cutting with the
grinding wheel.
• Always use the grinding wheel intended for a given power
tool and guard intended for a given grinding wheel. Grinding
wheel that are not part of equipment of a given power tool may be
insuciently covered or safe.
• Oset grinding wheels should be fastened so that their
grinding surface does not protrude beyond the protective
guard. Incorrectly seated grinding wheel and protruding beyond the
edge of the protective guard may not be suciently covered.
• The guard must be secured to the power tool to ensure the
highest possible safety level and positioned so that the
uncovered part of the grinding wheel facing the operator is
as small as possible. The guard protects the operator against chips,
accidental contact with the grinding wheel and sparks, which may
set clothing on re.
• Grinding wheels can only be used according to its purpose.
• The side surface of the grinding wheel should not be used
for cutting. Cut-o grinding wheels are designed for removal of
material with the disc edge. The inuence of lateral forces on the
grinding wheels may break them.
• Undamaged fastening anges of a correct size and shape
should always be used for a selected grinding wheel. Proper
anges support the grinding wheel and reduce the risk of its breaking.
Flanges for cut-o wheels may dier from anges designed for other
grinding wheels.
• Do not use worn grinding wheels from larger power tools.
Grinding wheels for larger power tools are not designed for higher
rotational speed, which is specic to smaller power tools. Thus, such
grinding wheels may break.
Additional specic safety guidelines for cutting with a cut-o wheel
• Always prevent a cut-o wheel from seizure and avoid
excessive pressure. Do not make too deep cuts. The overload of
a cut-o wheel increases its load and tendency for seizure or locking,
and thus may result in recoil or breaking of a cut-o wheel.
• Avoid areas in front of and behind a rotating cut-o wheel.
When a cut-o wheel is moved onto a workpiece away from the
operator, it may cause the power tool to kick back as a result of recoil,
with a rotating cut-o wheel pointing directly towards the operator.
• When a cut-o wheel seizes or you take a break from work,
switch o the power tool and wait until it comes to a complete
stop. Do not attempt to remove a rotating cut-o wheel from
a cutting place, since it may cause recoil. Find and eliminate a
cause of seizure.
• Do not switch the power tool back on, if it is still sunk in a
workpiece. Before you continue to cut, a cut-o wheel must
reach its full rotational speed. Otherwise, a cut-o wheel may
catch, spring back from a workpiece and cause recoil.
• Boards and large objects should be supported to reduce the
risk of recoil caused by a seized cut-o wheel. Large objects may
bend under their own weight. A workpiece should be supported from
both sides, both near the cut line and its edge.
• Special caution should be exercised, when holes are cut
in a wall or in conned spaces. As a cut-o wheel sinks into a
workpiece, it may cause the power tool to recoil, when it encounters a
gas or water supply line, power conductors or other objects.
Specic safety guidelines for sanding with sandpaper
• Do not use too large sheets of sandpaper. Always follow
guidelines of a manufacturer, when the size of a sandpaper is
selected. Sandpaper protruding beyond a grinding disc may cause
injuries and result in locking and tearing of sandpaper, or recoil.
Specic safety guidelines for working with wire brushes
• It should always be remembered that pieces of wire are lost
even during normal use. Do not overload wires by putting
excessive pressure. Airborne pieces of wire may easily puncture
thin clothing and/or skin.
• If a guard is recommended to be used, prevent a brush from
touching the guard. A brush diameter for plates and pots may
increase due to the pressure and centrifugal forces.
Additional safety guidelines
• Before connecting to the power source, always make sure the
supply voltage is compatible with the value specied on the
nameplate of the tool.
• Before the grinder is connected, always check the power
cord. In case of damage, have it repaired in an authorised
workshop.
• Before all installation works, the plug should be taken out of
the receptacle.
• Grinding tools should be checked before each use. A grinding
tool must be correctly fastened and should rotate freely. As
part of the test, the tool should be switched on with no load
for at least one minute in a safe position. Do not use damaged
or vibrating grinding tools. Grinding tools should be round.
Damaged grinding tools may break and cause injuries.
• Once a grinding tool is installed and before the grinder is
switched on, check the grinding tool for correct installation
and free rotations, and whether it does not catch the guard.
• The spindle lock button can be activated, only when the
grinder spindle does not move.
