Fluke 726 [25/80] Calibrators remote control interface 725 and 726

Calibrators

Remote Control Interface (725 and 726)

Table 4. Remote Commands for Sensor Selection (725 with V2.xx and lower)

Selection Entry

Serial Input No. Thermocouple Type RTD Type

S 1 J Pt100 (3926)

2 K Pt100 (385)

3 T Pt100 (3916)

4 E Pt200 (385)

5 R Pt500 (385)

6 S Pt1000 (385)

7 B Ni120

8 L -

9 U -

A N -

B mV -
