Fluke 726 [36/80] Lower display voltage measurement tests

724/725/726

Calibration Manual

Lower Display Voltage Measurement Tests

1. Press RESET on the 5520A.

2. Press  on the UUT until MEASURE and V appear on the lower display.

3. Make the connections shown in Figure 3.

4. Set up the 5520A to output each of the voltages in Table 9 and verify that the UUT

readings are within the limits shown.

5. Press STBY on the 5520A.

Table 9. Lower Display Voltage Readings

5520A Outputs 724/725 UTT Readings 726 UTT Readings

0.000 V -0.002 V to +0.002 V -0.002 V to +0.002 V

10.000 V 9.996 V to 10.004 V 9.997 V to 10.003 V

20.000 V 19.994 V to 20.006 V 19.996 V to 20.004 V
