Fluke 726 [78/80] Replaceable parts
![Fluke 726 [78/80] Replaceable parts](/views2/1436093/page78/bg4e.png)
724/725/726
Calibration Manual
70
Replaceable Parts
When servicing this Calibrator, use only the replacement parts specified. User-
replaceable parts are listed in Table 19 and shown in Figure 36.
Table 19. Replacement Parts
Item Description Fluke No. Quantity
724-725 Case top
726 Case top
664232
2491880
1
724 LCD mask
725 LCD mask
726 LCD mask
724 LCD mask for new LCD (FW rev 3.00+)
725 LCD mask for new LCD (FW rev 3.00+)
726 LCD mask for new LCD (FW rev 3.00+)
1548383
664273
2491914
4413712
4413701
4413720
1
Elastomeric strips 802063 2
724 Input/output bracket
725 - 726 Input/output bracket
1549921
691391
1
LCD bracket 658390 1
Mounting screws 494641 11
Backlight 690336 1
724 - 725 LCD for V2.xx or lower
726 LCD with V1.4 or lower
724-725 with V3.xx or higher
726 with V1.5 or higher
690963
2544712
4413845
4413845
1
724 Keypad
725 Keypad
726 Keypad
1548126
690955
2461532
1
Case bottom 664235 1
AA alkaline batteries 376756 4
Case screws 832246 4
Battery door 664250 1
Accessory mount 658424 1
Tilt stand 659026 1
Battery door 1/4-turn fasteners 948609 2
Not
Shown
Test leads Variable
[1]
1
Not
Shown
alligator clip, red
alligator clip, black
Variable
[1]
Variable
[1]
1
1
724 Case top decal
725 Case top decal
726 Case top decal
1548329
690948
2530988
1
