724/725/726
Calibration Manual
18
Serial Command List (726)
Table 5 lists the serial commands for the 726 and 725 Calibrator with V3.00 and higher
firmware. Refer to “Remote Control Interface (725 and 726)” for activation steps.
Table 5. Serial Command List-726 and 725 V3.00 and Later
Command Response/Actions
Command
Arguments
Comment Ch 1 Ch 2
*IDN? Returns the ID string
“FLUKE,726,0,{sw_rev}” where
sw_revision is the firmware
revision
Verify model
number and
firmware
revision
X X
FUNC? Returns {Upper},{Lower}
{Upper} responses
(Channel 1)
DCI, DCI_LOOP, DCV,
DCI_ERROR,
DCI_ERROR_LOOP
{Lower} responses
DCI, DCMV, DCV, DCI_SIM, TC,
RTD, FREQUENCY,
PULSE_TRAIN
Answers with
the configured
function for the
upper and
lower display
X X
VAL? Returns the measured value with
base units for the upper and lower
display
{upper_val},{upper_units},{lower_
val},{lower _units},
upper_units: V, A, PERCENT
lower _units: V, CEL, FAR, A,
OHM, CPM, HZ, COUNT
X X
UPPER_MEAS 1 argument, valid
settings: DCI,
DCI_LOOP, DCV,
DCI_ERROR,
DCI_ERROR_LOOP
Set upper
channel
measure mode X
