DGS-3048 Gigabit Ethernet Switch Manual
112
General
IEEE 802.1P Tagged Packets
IEEE 802.3ab 1000BASE-T
IEEE 802.3x Full-duplex Flow Control
ANSI/IEEE 802.3 NWay auto-negotiation
Protocols
CSMA/CD
Data Transfer Rates
Ethernet:
Fast Ethernet:
Gigabit Ethernet:
Half-duplex Full-duplex
10 Mbps 20 Mbps
100 Mbps 200 Mbps
2000 Mbps (Full duplex only)
Topology
Star
Network Cables
10BASE-T: UTP Category 3, 4, 5 (100 meters max.)
EIA/TIA- 568 150-ohm STP (100 meters max.)
100BASE-TX: UTP Cat. 5 (100 meters max.)
EIA/TIA-568 150-ohm STP (100 meters max.)
1000BASE-T: UTP Cat. 5e (100 meters max.)
UTP Cat. 5 (100 meters max.)
EIA/TIA-568B 150-ohm STP (100 meters max.)
1000BASE-LX: Single-mode fiber module (10km)
1000BASE-SX: Multi-mode fiber module (550m)
1000BASE-LHX: Single-mode fiber module (40km)
1000BASE-ZX: Single-mode fiber module (80km)
Mini-GBIC: SFP Transceiver for 1000BASE-LX
Single-mode fiber module (10km)
SFP Transceiver for 1000BASE-SX
Multi-mode fiber module (550m)
SFP Transceiver for 1000BASE-LHX
Single-mode fiber module (40km)
SFP Transceiver for 1000BASE-ZX
Single-mode fiber module (80km)
Number of Ports: 48 x 10/100/1000 Mbps ports
4 x GBIC combo ports
