D-Link DGS-3048 [37/147] Port description
![D-Link DGS-3048 [37/147] Port description](/views2/1043638/page37/bg25.png)
DGS-3048 Gigabit Ethernet Switch Manual
Port Description
Port settings are presented in following window. To open the Port Description Window click on the Port Configuration
folder and choose the Port Description link.
Figure 7- 4. Port Description Window
The following parameters can be set:
Parameter Description
From/To
These two fields allow you to specify the range of ports included in the description
Description
Text description of the port
User Accounts
The Switch allows you to set up and manage user accounts by using the following windows.
25
