DGS-3048 Gigabit Ethernet Switch Manual
Download Firmware
To update the Switch's firmware, click on the TFTP Services link in the Administration folder:
Figure 7- 13. TFTP Services Window
To download firmware, configure the following fields and click Start.
Parameter Description
Active
Select the activity type
Server IP Address
Enter the IP address of the server from which you wish to download firmware.
File Name
Specify the path and filename of the firmware on the Server.
35
