DGS-3048 Gigabit Ethernet Switch Manual
Bandwidth Control
Bandwidth control limits the amount of Multicast and Broadcast frames accepted and forwarded by the device.
When Layer 2 frames are forwarded, Broadcast and Multicast frames are flooded to all ports on the relevant
VLAN. This occupies bandwidth, and loads all nodes on all ports.
Figure 9- 2. Bandwidth Control Window
The following fields can be set:
Parameter Description
Port
Indicates the port from/to which storm control is enabled.
Rate
The maximum rate (kilobytes per second) at which unknown packets are forwarded
73
