DGS-3048 Gigabit Ethernet Switch Manual
Parameter Description
Allowed to go port
Allows the selection of the port number on which the MAC address entered above
resides.
Click Apply to implement the changes made. To delete an entry in the Static Unicast Forwarding Table, click the
corresponding
under the Delete heading.
Multicast Forwarding
The following window describes how to set up Multicast Forwarding on the Switch. Open the Forwarding folder and click
on the
Multicast Forwarding link to see the entry window below:
Figure 8- 17. Static Multicast Forwarding Settings Window
The
Static Multicast Forwarding Settings window displays all of the entries made into the Switch's static multicast
forwarding table. Click the
Add button to open the Setup Static Multicast Forwarding Table window, as shown below:
Figure 8- 18. Setup Static Multicast Forwarding Table Window
61
