VID) as the ingress port. If it does not, the packet is dropped. If it has the same VID, the packet is forwarded and the
destination port transmits it on its attached network segment.
This process is referred to as ingress filtering and is used to conserve bandwidth within the Switch by dropping packets that
are not on the same VLAN as the ingress port at the point of reception. This eliminates the subsequent processing of packets
that will just be dropped by the destination port.
Default VLANs
The Switch initially configures one VLAN, VID = 1, called "default." The factory default setting assigns all ports on the
Switch to the "default."
Packets cannot cross VLANs. If a member of one VLAN wants to connect to another VLAN, the link must be through an
external router.
NOTE: If no VLANs are configured on the Switch, then all packets will be
forwarded to any destination port. Packets with unknown source
addresses will be flooded to all ports. Broadcast and multicast packets will
also be flooded to all ports.
An example is presented below:
VLAN Name VID Switch Ports
System (default) 1 5, 6, 7, 8, 21, 22, 23, 24
Engineering 2 9, 10, 11, 12
Marketing 3 13, 14, 15, 16
Finance 4 17, 18, 19, 20
Sales 5 1, 2, 3, 4
Table 8-1. VLAN Example - Assigned Ports
VLAN and Trunk Groups
The members of a trunk group have the same VLAN setting. Any VLAN setting on the members of a trunk group will apply
to the other member ports.
NOTE: In order to use VLAN segmentation in conjunction with port trunk
groups, you can first set the port trunk group(s), and then you may
configure VLAN settings. If you wish to change the port trunk grouping with
VLANs already in place, you will not need to reconfigure the VLAN settings
after changing the port trunk group settings. VLAN settings will
automatically change in conjunction with the change of the port trunk
group settings.
VLAN status
This allows the VLAN status for each of the Switch's ports to be viewed by VLAN. This window displays the ports on the
Switch that are currently Egress or Tag ports. To view the following table, open the L2 features->VLAN folder and click
the VLAN Status Link.
