11D-Link DIR-685 User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
The DIR-685 has LEDs for Power, WPS, and Hard Drive Status.
See the table below for detailed information about the LEDs:
LED INDICATOR COLOR STATUS DESCRIPTION
Power Blue
Off The device is powered off.
Solid Blue The device is powered on.
WPS Blue
Off WPS is ready to be triggered.
Blinking Blue WPS has been triggered and is processing.
Solid Blue
WPS signal has been successfully established.
The LED will remain solid blue for 5 seconds.
Unmount
(Hard Drive Status)
Blue
Off No hard drive detected.
Blinking Blue Hard drive is busy or the system is mounting the hard drive.
Solid Blue Hard drive has been detected and is idle.
Orange
Blinking Orange System is un-mounting the hard drive.
Solid Orange The hard drive can be removed safely.
