1D-Link DIR-685 User Manual
Section 1 - Product Overview
Product Overview
Note: Using a power supply with a different voltage rating than the one included with the DIR-685 will cause damage and void the warranty.
D-Link DIR-685
Xtreme N
™
Storage Router
Power Adapter
Ethernet Cable
CD-ROM
Stand
Package Contents
