62D-Link DIR-685 User Manual
Section 3 - Configuration
QoS Engine
The speed at which data can be transferred
from the router to your ISP. This is determined
by your ISP.
The speed at which data can be transferred from
the Internet to your router. This is determined
by your ISP.
Tick this box to automatically set the priority for
your applications.
Uplink Speed:
Downlink Speed:
Lag Eliminated:
The QoS Engine option helps improve your network gaming performance by prioritizing applications. By default the
QoS Engine settings are disabled and application priority is not classied automatically.
