86D-Link DIR-685 User Manual
Section 3 - Configuration
Carry out the following steps to edit a FTP Access List:
Editing an FTP Access List
FTP Server
In the FTP Access Lists section, 1.
click the Notepad icon next to the
FTP Access List you want to edit.
