88D-Link DIR-685 User Manual
Section 3 - Configuration
Carry out the following steps to delete a Network Access List:
Deleting an FTP Access List
FTP Server
In the FTP Access List section, click the 1.
Trash Can icon next to the FTP Access
List you want to delete.
The following dialog box 2.
appears. Click the OK button
to delete the FTP Access List.
