110D-Link DIR-685 User Manual
Section 4 - Security
From the Setup > Wireless Setup screen, click the Manual
Wireless Connection Setup button.
Add Wireless Device with the WPS Wizard
PIN: Select this option to use PIN method. In order to use this
method you must know the wireless client’s 8 digit PIN and
click Connect.
Push Button: Select this option to use PBC (Push Button)
method to add a wireless client. Click Connect.
Click the Add Wireless
Device with WPS button.
