DLB-1200 Network Load Balancer User Manual
Source Port
Please enter the data-packets Source Port Number.
Destination Address
Please enter the data-packets Destination IP Address.
Destination Netmask
Please enter the data-packets Destination Subnet Mask.
Destination Port
Please enter the data-packets Destination Port Number.
Service
Please choose the data-packet type, either TCP or UDP.
Action
Please choose "DENY" to restrict illegal network access. The rest traffic is allowed by default.
2. Firewall Policy List
All Firewall Policy you set will show in the ""Firewall Policy List". If you want delete one policy,
just click the policy, and then click "Delete".
NOTE：After you entered above essential data in this page/item, you have to click the "Save"
button on right below of the screen.
3-4、Network Info
The Network Info can clearly and immediately let you see the current network situation and
information, including WAN/LAN configuration and usage status, administrator user name and
password, etc. You can change the user name and password in this item.
