DLB-1200 Network Load Balancer User Manual
A
PPENDIX
B
Trouble Shooting
This chapter covers some common problems that may be encountered while using the
DLB-1200 and some possible solutions to them. If you have followed the suggested steps and
the DLB-1200 still didn't function properly, please contact your dealer for further advice.
General Problems
♦ Problem 1: Can't connect to the DLB-1200 to configure it.
♦ Solution 1: Check the following:
1、 The DLB-1200 is properly installed, LAN connections are OK, and it is powered ON.
2、 Ensure that your PC and the DLB-1200 are on the same network segment. (If you don't
have a router, this must be the case.)
3、 If your PC is set to "Obtain an IP Address automatically" (DHCP client), restart it.
4、 If your PC uses a Fixed (Static) IP address, ensure that it is using an IP Address within the
range 192.168.0.2 to 192.168.0.254 and thus compatible with the DLB-1200's default IP
Address of 192.168.0.1. Also, the Network Mask should be set to 255.255.255.0 to match
with DLB-1200. In Windows, you can check these settings by using Control Panel-Network
to check the Properties for the TCP/IP protocol.
Internet Access
♦ Problem 1: When I enter a URL or IP address I get a time out error.
♦ Solution 1: A number of things could cause this. Try the following
troubleshooting steps.
1、 Check if other PCs work fine. If they do, ensure that your PCs IP settings are correct. If
using a Fixed (Static) IP Address, check the Network Mask, Default gateway, DNS and IP
Address.
2、 If the PCs are configured correctly, but still not working, check the DLB-1200. Ensure that
it is connected and interfaces status are ON. Connect to it and check its settings. (If you
can't connect to it, check the LAN and power connections.)
3、
If the DLB-1200 is configured correctly, check your Internet connection (DSL/Cable
modem etc) to see that it is working correctly.
40
